TM62511M-3T3X
AccuThread® T3 Solid Carbide Threadmill: UN 11, 5/8", Helical 4 Flute, AM210®
AccuThread® T3

Add to cart image Add to list image







Default Image
Angle
Front
Side
Product Specifications
Thread Style Internal/External
Depth to Diameter 3X
Weldon Flat (Yes/No) No
Material Carbide
Overall Length (mm) 88.9
Pitch 11
Number of Flutes 4
Coating AM210®
Shank Type Cylindrical
Type of Product Solid Carbide Threadmill
Minimum Thread Size 5/8"
Cutter Diameter (mm) 11.94
Length of Cut (mm) 47.63
Shank Diameter (mm) 12
Flute Type Helical
Cutting Direction Left Hand (M04)
Thread Standard UN
Coolant Through No
Ordering Information
Package Qty 1
Min. Order Qty 1
Weight in lbs (each) 0.25
Weight in kg (each) 0.11
Category Stocked
