4335-MC-060
ALVAN® Ring Arbor: 1.7953" - 1.9527", Radial Coolant, Modular Shank
ALVAN® Ring Arbor

Add to cart image Add to list image







Default Image
Main
Product Specifications
Type of Product Modular Reamer Body
Series 4335
Minimum Diameter (inch) 1.7953
Maximum Diameter (inch) 1.9527
Assembled Reference Length (inch) 3.15
Length of Cut (inch) 2.362
Length Type Extra Short
Modular Shank Size (mm) 50
Shank Type Modular
Adjustment location Front
Application Type Blind Hole
Coolant (Yes/No) Radial Coolant
Ordering Information
Package Qty 1
Min. Order Qty 1
Weight in lbs (each) 0.407
Weight in kg (each) 0.18
Category Non-Stock*
*Non-stocked items are NON-RETURNABLE. They are also subject to PROCESS FEES. Process fees are not included in the list price. Please refer to the price list for a breakdown of those fees.
