APX Drill
Allied's APX delivers the strength and versatility needed for any deep hole drilling application. The APX geometry is designed to increase penetration rates and tool life, providing the lowest cost per hole among deep hole drilling lines.
Advantages
  • Pilot insert stabilizes the tool through the cut
  • Outboard indexable carbide inserts achieve the final cutting diameter
  • Allows for higher penetration rates
  • Takes advantage of the power curve on modern CNC machines for maximum penetration rates on deep holes
Features
  • Utilizes either T-A® or GEN3SYS® Inserts as pilots
  • Up to 10xD
  • Modular head connection
  • 11 different series to cover a diameter range of 33 mm -101.6 mm (1.299" - 4.00")
  • Multiple geometries and substrates for a variety of materials
Recommended Materials
Materials
x
Steel
High Temp Alloy
Stainless Steel
Hardened Steel
Cast Iron
Aluminum
Icon Reference




Recommended Industries
Industries
x
Medical
Renewable Energy/ Energy
Automotive
Aerospace
Firearms
Agriculture
Oil and Gas
Marine
General Production
Heavy Equipment
Hydraulics
Tool, Mold, and Die
Structural Steel Fabricator
Icon Reference



APX Drill Rotate
APX Drill Rotate
APX Drill Angle
APX Drill Side 1
APX Drill Side 2
APX Drill Close
APX Drill Explosion
Technical Information

Product Specifications
Product Type
Modular Indexable Drill System
Diameter Range
1.299" - 4.000" (33.00mm - 101.6mm)
Coating
TiN, TiAlN, TiCN
Modular Head
T-A Pilot, GEN3SYS® Pilot
IC Insert
Trigon with AM300® Coating
Holder
APX Body
Flute Options
Helical
Shank Options
Flanged Shank, CV40, CV50
Drill Depth
3xD 5xD 8xD 10xD
Coolant
Coolant Through

Product Nomenclature
APX Drill Heads
APX Head
x
V = Head
V
Series
x
33 = 33 series
38 = 38 series
44 = 44 series
51 = 51 series
63 = 63 series
70 = 70 series
76 = 76 series
83 = 83 series
89 = 89 series
95 = 95 series
38
Pilot Series
x
T-A Pilot Insert:
00 = 0 series
01 = 1 series
02 = 2 series
GEN3SYS XT Pilot Insert:
15 = 15 series
17 = 17 series
18 = 18 series
20 = 20 series
22 = 22 series
24 = 24 series
26 = 26 series
29 = 29 series
32 = 32 series
15
Effective Cutting
x
D = Double effective
S = Single effective
D
-
Major Diameter
x
0116 = Inch
1.5153 = Decimal
68 = Metric
0116
APX Drill Holders
APX Holder
x
W = Holder
W
Series
x
33 = 33 series
38 = 38 series
44 = 44 series
51 = 51 series
57 = 57 series
63 = 63 series
70 = 70 series
76 = 76 series
83 = 83 series
89 = 89 series
95 = 95 series
38
Drill Length
x
03 = 3xD
05 = 5xD
08 = 8xD
10 = 10xD
05
Flute Style
x
H = Helical
H
-
Shank
x
150F = 1-1/2" flanged straight shank
200F = 2" flanged straight shank
40FM = 40mm flanged staright shank
50FM = 50mm flanged straight shank
CV40 = CAT40 integral shank
CV50 = CAT50 integral shank
200F
APX Drill
Deep Hole / Large Diameter Drilling

Available Online Only

Recommended Cutting Data
